Overview

Basic Info.

Model NO.	LDA
Condition	New
Operation Form	Air Operation+Ground Operation
Maximum Lifting Height	10-15m
Maximum Lifting Weight	<20t
Main Girder Form	Single Girder
Type	Ordinary
Power Supply	AC-3phase-220/380/400/415/440V-50/60Hz
Span	7.5-22.5m
Hoisting Mechanism	Hoist/ Trolley
Working Class	A3
Painting Color	Customized
Product Name	Single Girder Overhead Crane
Transport Package	High Quality Plywood Crates
Trademark	KUANGYUAN
Origin	China
HS Code	8426112000
Production Capacity	5000 Pieces a Year

Packaging & Delivery

Package Size 1700.00cm * 2500.00cm * 2000.00cm Package Gross Weight 2000.000kg

Product Description

LDA Type Single Girder Overhead Crane for WorkshopProduct Description

Single girder overhead crane configuration is made up of a single bridge girder, two end carriages and a hoist with trolley, which
runs along the bottom flange of the bridge girder between the end carriages.

LDA model single girder crane is a kind of light duty crane, with the capacity of 1 to 20 tons. The span is 7.5to 31.5 meters. Working duty is A3 A4. Working environment temperature is -20°C to 40°C.

LDA model single girder crane consists of main beam,end beam,electric hoist,festoon cable and electric control system,It is widely used in plants, warehouse, and material stocks to lift goods.

LDA model single girder crane is matched with electric hoist which is CD model or MD model.

It is prohibited to use the equipment in the combustible, explosive or corrosives environment.

Product Parameters

Capacity			t	3	5	10	16	20
Operational method				Pendent line with press button /cabin/remote control
Speed	Hoisting		m/min	8. 8/0.8		7. 7/0.7	3.5, 3.5/0.35	6. 6/0.6
	Travelling of crab			20
	Travelling of crane	Surface		20(30)				20
		Cabin		20(30)				20
Electric hoist			Type	CD1-3 MD1-3	CD1-5 MD1-5	CD1-10 MD1-10	CD1-16 MD1-16
Lifting height			m	6,9,12	6,9,12,18	9,12	9,12	9,12
Working class				A3~A5
Power supply				3-phrase 50HZ 380V

Certifications

Company Profile

Henan Mine Crane Co.,Ltd is the largest industrial crane manufacturer in China since 2002. Main products are Electric hoist/Overhead crane/Gantry crane/Grab crane/Magnet crane/Ladle Lifting crane/Explosion proof crane/Rail Mounted Container Gantry Crane/European type Single Beam or Double Beam Overhead Crane and Gantry crane and hoist /Electric Winch,Cantilever Jib crane,Hydraulic Scissor Lift/Crane parts and components.
Henan Mine Crane company has 4500staffs,1420000m2 workshop area,3500sets of various advanced equipments,yearly sales 100000sets of crane and hoist, has obtained ISO,CE,EAC,GOST, etc certifications, cranes and hoists have been exported to 120countries.
In Pakistan,we have supplied our cranes to Abbas Steel Group,Almoiz industries Ltd,Fareed Engineering works,Tariq Glass Industies Ltd.
Besides Pakistan,we also supplied our cranes to India,Bangladesh,Philippines,Uzbekistan,Cameroon,Egypt,Ethiopia,Nigeria,Morocoo,Algeria.
If you are interested in our cranes,welcome you contact me any time
