Basic Info.
Model NO. | SJY0.5-6 |
Feature | Explosion-Proof, Insulating |
Certification | CE, ISO 9001 |
Lifting Time (S) | 54 |
Rated Load (Kg) | 500 |
Travel Motor Power (Kw) | 0.75 |
Motor Power (Kw) | 1.1 |
Voltage (V/Hz) | 380/50 |
Max Working Height (mm) | 8000 |
Platform Size (mm) | 1780×840 |
Max Platform Height (mm) | 6000 |
Delivery | 15 Days, or Rushed as Required |
Transport Package | Steel Pallet+Buffer Sponge+Bubble Bag+Waterproof |
Specification | 850 KG |
Trademark | Boonai |
Origin | Xiangcheng District, Suzhou, China |
HS Code | 8428909090 |
Production Capacity | 200 Units Per Month |
Product Description
Self-propelled Scissor Lift (economy) Max platform (6m)Application: It is widely used for aerial installation and maintenance of the working sited such as hotel, grand hall, sport stadium, large factory, workshop, warehouse, granary, bus or railway station, airport, gas station and aerial pipeline. Repairing street lamp Working at height Outdoor installation Large factory Exhibition hall AerodrameCompany information
Max height of platform:3m,4.5m,6m,7.2m,9m,11m,12m for option.
1.Made of Manganese steel, enabling heavy loading2.Scissor mechanism provides high stability when lifting3.More than one operator could be carried simultaneously with equipped large platform4.Mainly used in station, dock, plant and construction site for aerial working in case of machinery installation, equipment and building maintenance
1.AC380V2.Emergency Lowering valve3.Leveling device with supporting screw4.Waterproof electric box5.Emergency stop button
Parameters Table
Model | Max platform height (mm) | Rated load (kg) | Overall weight(kg) | Platform size (mm) | Overall L*W*H (mm) | AC(VAC/kw) |
SJY0.3-3 | 3000 | 300 | 450 | 1150×700 | 1250*850*960 | 0.75 |
SJY0.5-3 | 3000 | 500 | 1150×700 | |||
SJY0.3-4.5 | 4500 | 300 | 560 | 1780×840 | 1900*1000*1000 | 1.5 |
SJY0.5-4.5 | 4500 | 500 | 1780×840 | |||
SJY0.3-6 | 6000 | 300 | 850 | 1780×840 | 1900*1000*1120 | 1.5 |
SJY0.5-6 | 6000 | 500 | 1780×840 | |||
SJY0.3-7.2 | 7200 | 300 | 1270 | 2000×1000 | 2100*1250*1650 | 1.5 |
SJY0.5-7.2 | 7200 | 500 | 2000×1000 | |||
SJY0.3-9 | 9000 | 300 | 1500 | 2000×1000 | 2100*1250*1800 | 2.2 |
SJY0.5-9 | 9000 | 500 | 2000×1000 | |||
SJY1-9 | 9000 | 1000 | 1900 | 2100×1200 | 2200*1450*1770 | 4 |
SJY0.3-11 | 11000 | 300 | 1700 | 2100×1200 | 2200*1450*1810 | 2.2 |
SJY0.5-11 | 11000 | 500 | 2100×1200 | |||
SJY1-11 | 11000 | 1000 | 2860 | 2300×1350 | 2400*1600*1990 | 4 |
SJY0.3-12 | 12000 | 300 | 2400 | 2400×1350 | 2500*1600*1950 | 3 |
SJY0.5-12 | 12000 | 500 | 2400×1350 | |||
SJY1-12 | 12000 | 1000 | 2900 | 2400×1350 | 2500*1600*1910 | 4 |
Part or Customers
Packing
Warranty
1. User-friendly English manual for machine using and maintenance.2. One year warranty for whole machine without man-made fault.3. We will send you parts for free if there are any non-human factors problem duringwarranty time.4. 24-hours technical support by email, telephone or other communication online.5. We could reply you in 2 hours after received your any questions even on weekend andholidaysm engineers are available to your company if necessary.
